With integrated thermal shutdown and overcurrent protection, this IC ensures safe operation under all conditions. Available in both TO-92 and SOT-89 packages, it supports both through-hole and surface-mount PCB designs.
Note: Use a 0.33µF capacitor on the input and a 0.1µF capacitor on the output for best performance and stability.
-48%
CJ78L15 Voltage Regulator IC 15V 3-Terminal LDO Regulator
Available:In Stock
- Product SKU: INTEG210
₹ 15
₹ 29
Need Volume Discounts? Deals are specially designed for you. Click here
Need Customization? Provide us more details Click here
🏠
Warehouse Details:
Specification
Description
CJ78L15 Voltage Regulator IC – 15V 3-Terminal LDO Regulator
The CJ78L15 is a compact 3-terminal low dropout (LDO) linear voltage regulator IC designed to provide a steady 15V output for low-power electronic circuits. It can deliver up to 100mA current, making it ideal for analog modules, microcontrollers, and low-current embedded systems.With integrated thermal shutdown and overcurrent protection, this IC ensures safe operation under all conditions. Available in both TO-92 and SOT-89 packages, it supports both through-hole and surface-mount PCB designs.
Note: Use a 0.33µF capacitor on the input and a 0.1µF capacitor on the output for best performance and stability.
Technical Details
- IC Name: CJ78L15
- Type: Fixed 15V Low Dropout Voltage Regulator
- Output Voltage: 15V ±5%
- Output Current: Up to 100mA
- Input Voltage Range: 17V to 35V
- Dropout Voltage: ~1.7V typical
- Quiescent Current: ~5mA
- Line Regulation: Max 210mV
- Load Regulation: Max 100mV
- Internal Thermal Shutdown
- Short Circuit and Overcurrent Protection
- Package: TO-92 / SOT-89
- Mounting Type: Through-hole / SMT
- Operating Temperature: -40°C to +125°C
Features
- Fixed 15V regulated output
- Provides up to 100mA current
- Low dropout voltage and quiescent current
- Built-in thermal and overcurrent protection
- Available in TO-92 and SOT-89 package types
- Simple 3-pin configuration for easy integration
- Ideal for analog and embedded applications
Applications
- Analog signal processing modules
- Microcontroller and sensor systems
- Battery-powered and portable electronics
- Low-current 15V electronic circuits
- DIY, repair, and educational kits
Physical Attributes
- Available Packages: TO-92 (Bulk) / SOT-89 (SMT)
- Pin Count: 3
- TO-92 Dimensions: ~4.5mm x 4.0mm x 5.0mm (W x D x H)
- SOT-89 Dimensions: ~4.5mm x 2.5mm x 1.6mm
- Mounting Type: TO-92 – Through-hole, SOT-89 – Surface Mount
- Weight: ~0.2g (TO-92), ~0.1g (SOT-89)
Package Includes
- 1 x CJ78L15 Voltage Regulator IC (TO-92 or SOT-89, as selected)
